Black RV 2-3.2 Insulated Wire Terminals 37A Current Copper Wire Ring Terminals
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Another Name: | Rohs Insulated Terminals | Certificate: | ISO9001 ROHS CE SGS |
|---|---|---|---|
| Samples: | Provide Free Samples | Wire Range: | 2.5-4mm2 |
| Max Current: | 37A | Insulator Color: | Black |
| High Light: | insulated crimp terminals,quick disconnect terminals |
||
Black RV 2-3.2 Insulated Wire Terminals 37A Current Copper Wire Ring Terminals
WENZHOU RV TYPE TU-JTK Pre-insulated Ring Terminal(Cable terminal)
American Standard Specification RV Automotive Crimp Ring Terminal Lug Tin TU-JTK
100% Inspection
Our Services:
1. Perfect package according to your demand.
2. Mark your logo if you want.
2. New product can be made accurately by your design and demand.And in 7 days finished.
Shipping term:
If small quantity, usually send by courier (DHL,FEDEX,TNT and so on) . If big quantity, we advice ship by
air or by sea. this will use longer time , but cheaper fees. We are near NINGBO and SHANGHAI port.
|
Wire Range
|
2.5-4mm2
|
|
A.W.G.
|
14-12
|
|
Max Current
|
37A
|
Item No |
Stud size |
Dimension(mm) | Color |
|||||
| d2 | B | L | F | H | Dφ | |||
| RV3.5-4 | #8 | 4.3 | 8.0 | 24.5 | 7.7 | 13.0 | 6.2 | Black |
| RVS3.5-5 | #10 | 5.3 | 8.0 | 24.5 | 7.7 | |||
| RVL3.5-5 | #10 | 5.3 | 12.0 | 27.9 | 7.7 | |||
| RV3.5-6 | 1/4 | 6.4 | 12.0 | 27.9 | 7.7 | |||
| RV3.5-8 | 5/16 | 8.4 | 15.0 | 32.0 | 13.5 | |||
| RV3.5-10 | 3/8 | 10.5 | 15.0 | 32.0 | 13.5 | |||
-------------------------------------------------------------------------
