Insulated High Voltage Switch Electrical Quick Disconnect Outdoor ROHS CE Approval
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Samples: | Provide Free Samples | Wire Range: | 0.5-1.5mm2, 1.5-2.5mm2, 4-6mm2 |
|---|---|---|---|
| Another Name: | Switch Disconnect | Max Current: | 10A 15A 24A |
| Certificate: | ISO9001 ROHS CE SGS | Material: | Brass With Tin Plated, PVC |
| High Light: | wire crimp terminals,plastic wire connectors |
||
PBDD Insulated high voltage switch Electrical Quick Disconnect outdoor ROHS CE approval
Headline:
PBDD Insulated high voltage switch disconnect outdoor ROHS CE approval
Shipping:
Sample order: we send them by express like DHL, TNT, UPS etc.
Bulk order: shipped by sea, by air or as customer's request.
Packing:
OUT PACKING: 30000 pcs wire connector in Export Box size is 31 * 34 * 37CM
INNER PACKING: 100pcs per bag, or per customer's request.
Product Description:
| Usage | Wire Connection. |
| Feature | High Quality |
| Material | Copper,Nylon,PVC,Brass |
| Color | Red,Yellow,Blue |
| Packaging | Pack as customers' requests |
| Alibaba Trade Assurance Suppliers | Yes |
| Certification | CE SGS ROHS |
| Cable tie paypal | T/T, Western Union, Paypal |
| Shipping port | Ningbo or ShangHai |
|
Wire Range
|
0.5-1.5 mm2
|
|
A.W.G.
|
22-16
|
|
Max Current
|
10A
|
|
Wire Range
|
1.5-2.5 mm2
|
|
A.W.G.
|
16-14
|
|
Max Current
|
15A
|
|
Wire Range
|
4-6 mm2
|
|
A.W.G.
|
12-10
|
|
Max Current
|
24A |
Item No |
(mm) Nema Tab |
Dimension(mm) | Color |
|||||
| B | B1 | H | Dφ | dφ | L | |||
| PBDD1.25-250 | 0.8×6.35 | 7.4 | 6.4 | 10.0 | 3.8 | 1.7 | 21.5 | Red |
| PBDD2-250 | 0.8×6.35 | 7.4 | 6.4 | 10.0 | 4.3 | 2.3 | 21.5 | Bule |
| PBDD5.5-250 | 0.8×6.35 | 7.4 | 6.4 | 13.0 | 5.7 | 3.4 | 25.0 | Yellow |
Our advantage:
1. We are manufacturers of Cable lug with automatic machines, professonal development, production and inspection teams.
2. We produce high quality products. Free samples can be sent to you for test.
3. Our sales are all with more than 5 years working exprience. They can help you if you have any problem on product, trade process, after sales etc.
4. Fast delivery for bulk order, enough stock for sample and trial orders.
5. OEM / DEM is welcome.
6. Welcome to visit our factory.
