Product Details:
Payment & Shipping Terms:
|
Another Name: | Butt Connector | Certificate: | ISO9001 ROHS CE SGS |
---|---|---|---|
Samples: | Free Samples | Wire Range: | 0.5-1.5mm2, 1.5-2.5mm2, 4-6mm2 |
Color: | Red Blue Yellow | Material: | Copper With Tin Plated, PVC |
High Light: | nylon quick disconnects,copper wire connectors |
Product parameters:
Max current: 19A 27A 48A
Materials: PVC and Copper
Surface: Tin plated
AWG: 22-16 16-14 12-10
Wire Size: 0.5-1.5mm, 1.5-2.5mm, 4-6mm
Sample time: Free Samples Within 2 days
Packing Details:
1: Packing with double-wall carton, so it is very stronger.
2: Packing with plastic or wood pallet.
3: We can help to print your logo on carton.
4: Packing size can be Designed or customized for u.
Inner packing: 2000pcs / plastic bag, Outer packing: standard export carton, package also could according your requirements.
Product Name
|
Insulated Wire Connectors TL-JTK PVT
|
|
Terminal Body
|
Copper | |
Color
|
Red Insulation: Conductor size 0.5-1.5mm2 / 22-16awg.
|
|
Blue Insulation: Conductor size 1.5-2.5mm2 / 16-14awg.
|
||
Yellow Insulation: Conductor size 4.0-6.0mm2 / 12-10awg.
|
||
PVC
|
||
Plating
|
Tin
|
Item No |
Dimension(mm) | Wire range | Color |
|||||
I | dφ | L | A.W.G. | mm2 | ||||
PVT1.25 | 8.0 | 1.7 | 16.0 | 22-16 | 0.5-1.5 | Red | ||
PVT2 | 8.0 | 2.3 | 16.0 | 16-14 | 1.5-2.5 | Bule | ||
PVT5.5 | 8.5 | 3.4 | 20.5 | 12-10 | 4-6 | Yellow |
Our service:
(1) Free samples to test the quality.
(2) Very competitive price .
(3) Pack according to customer's requirement.
(4) Customizable different copper cable lug.
(5) Good quality, fast lead time.
transport:
Normally, the terminal you order will be sent by express when the payment is clear(Quantity is small).
Also, we can transport the goods by air or by sea(Quantity is big).
-------------------------------------------------------------------------
Packing:
Our normal packing is 100pcs per bag, one bag in a box, outside by export carton.
We also can pack as customers' requirements.
